PRODUK ICA UPS dan STABILIZER
ICA UPS CN-650 Capacity 650 VA, inverter only works when the AC input voltage is low or loss. When the AC input voltage is in normal condition, ICA UPS will stabilize and filter the AC input voltage and supply a clean and stable AC voltage to the ICA UPS output and charge the battery. When the AC input voltage is low or loss, inverter will replace it and supply a stable AC voltage within a very short transfer time.
TECHNICAL INFORMATION :
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PRODUK ICA UPS dan STABILIZER
ICA UPS CN-1300 Capacity 1300 VA, inverter only works when the AC input voltage is low or loss. When the AC input voltage is in normal condition, ICA UPS will stabilize and filter the AC input voltage and supply a clean and stable AC voltage to the ICA UPS output and charge the battery. When the AC input voltage is low or loss, inverter will replace it and supply a stable AC voltage within a very short transfer time.
TECHNICAL INFORMATION :
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PRODUK ICA UPS dan STABILIZER
ICA UPS CP-1400 Capacity 1400 VA, inverter only works when the AC input voltage is low or loss. When the AC input voltage is in normal condition, ICA UPS will stabilize and filter the AC input voltage and supply a clean and stable AC voltage to the ICA UPS output and charge the battery. When the AC input voltage is low or loss, inverter will replace it and supply a stable AC voltage within a very short transfer time.
TECHNICAL INFORMATION :
| Description | : | UPS CP1400 |
| Capacity | : | 1400 VA / 700 W |
| AC Voltage | : | 160 – 250 V |
| AC Current | : | 2.9 A |
| AC Frequency | : | 50 ± 3 Hz |
| AC Protection Fuse | : | 5 A |
| DC INT Battery | : | 2 x 12 V, 7 Ah |
| DC Protection Fuse | : | 40 A |
| INV Waveform | : | SYNTHESIZED SINEWAVE |
| INV Voltage | : | 220 ± 5% V |
| INV Frequency | : | 50 ± 1% Hz |
| INV Efficiency | : | >80 % |
| CHG Type | : | CONSTANT VOLTAGE |
| CHG Voltage | : | 27.2 V |
| CHG Current | : | 1.5 A |
| Transfer Time | : | <4 ms |
| Back Up Time | : | 10 min |
| Indicator | : | LED & BUZZER |
| Opera Temp | : | 0 – 40 °C |
| Dimension(DxWxH) | : | 375 x 135 x 201 mm |
| Weight | : | 14 Kg |
PRODUK ICA UPS dan STABILIZER
ICA UPS PN-302B Capacity 600 VA, inverter only works when the AC input voltage is low or loss. When the AC input voltage is in normal condition, ICA UPS will stabilize and filter the AC input voltage and supply a clean and stable AC voltage to the ICA UPS output and charge the battery. When the AC input voltage is low or loss, inverter will replace it and supply a stable AC voltage within a very short transfer time.
TECHNICAL INFORMATION
| Description | : | UPS UPS302B |
| Capacity | : | 600 VA / 300 W |
| AC Voltage | : | 160 – 250 V |
| AC Current | : | 1.7 A |
| AC Frequency | : | 50 ± 5% Hz |
| AC Protection | : | Fuse 6.3 A |
| DC INT Battery | : | 1 x 12 V, 7 Ah |
| DC EXT Battery | : | 1 x 12 V, Max 40 Ah |
| DC Protection Fuse | : | 40 A |
| INV Waveform | : | SYNTHESIZED SINEWAVE |
| INV Voltage | : | 220 ± 5% V |
| INV Frequency | : | 50 Hz |
| INV Efficiency | : | >80 % |
| CHG Type | : | CONSTANT VOLTAGE |
| CHG Voltage | : | 13.5 V |
| CHG Current | : | 1.5 A |
| Transfer Time | : | <4 ms |
| Back Up Time | : | 10 min |
| Indicator | : | LED & BUZZER |
| Opera Temp | : | 0 – 40 °C |
| Dimension(DxWxH) | : | 401 x 260 x 170 mm |
| Weight | : | 14.5 Kg |
